ECG

Highly conductive, multi-purpose electrolyte meets all the standards of the ideal saline electrode gel. Recommended for ECG, defibrillation, biofeedback and EMG.

• Highly conductive
• Bacteriostatic
• See-thru tube with stand-up cap lets you know how much SIGNAGEL is left
• Water soluble, non-staining, non-gritty

• Compatible with all seca ECG machines
• Easy height adjustment by using the foot pedal
• Braked castors for more stability and safety
• Cable covers and cord organiser helps protect leads
• Storage bin with dividers for accessories
• Easy to clean and disinfect
• 3 years warranty

ECG Paper for CT8000P-2 (Z-Fold - A4)

The latest KardiaMobile 6L from AliveCor produces a medical grade 6 lead ECG recording that gives you and your Doctor a more complete view of your heart using a free iOS and Android App. It's the first and only FDA cleared and CE-marked six lead personal ECG.

EKG on the go

• Enjoy the peace of mind - KardiaMobile 6L lets you take an EKG anytime, anywhere. If you feel a symptom, or just want the peace of mind, simply take an EKG, and in 30 seconds know if your heart rhythm is normal or if Atrial Fibrillation is detected.


• Trusted by doctors - Kardia has delivered more than 40 million EKGs and is recommended by leading cardiologists worldwide. With Kardia you can take EKGs between doctor visits, whenever you feel a symptom and email unlimited EKGs directly to your doctor.


• Using KardiaMobile 6L couldn't be easier - Simply open the Kardia app on your phone, and tap "record EKG. Place your thumbs on the top sensors, and touch the bottom sensor to the bare skin of your left leg (knee or ankle). In 30 seconds you'll see your results.

The KardiaMobile ECG has 2 electrodes in the front and one on the back. The two electrodes on the top are for your fingers, and the one on the bottom to contact the skin of your left leg. To record a 6 lead ECG hold the KardiaMobile 6L in your hands, placing your fingers on the front electrodes then touch the third electrode to the skin of your left knee or ankle. It's that easy.

What six leads does it record? The KardiaMobile 6L displays and records 30 seconds of Lead I, Lead II, Lead III, aVR, aVL and aVF ECG in real time to your phone or tablet. This gives it the increased ability to identify cardiac arrhythmias such as atrial flutter, heart block and PVCs.

ECGs are stored in the app which at the end of the recording displays the ECG trace, heart rate and classifies the recording into 1 of the following categories.

• Atrial Fibrillation. The clinically validated algorithm will notify you to the presence of atrial fibrillation. If AF is detected, you will see the message "Possible AF Detected."
• Normal. If no rhythm abnormalities are detected, you will receive the message 'Normal'. This means that the heart rate is between 50 and 100 BPM, there are no or very few abnormal beats, and the shape, timing and duration of each beat is considered normal.
• Bradycardia a slow heart rate below 40-50 beats per minute.
• Tachycardia a fast heart rate above 100-140 beats per minute.
• Unclassified. The Normal Algorithm declares the ECG as Unclassified for ECGs that have a heart rate below 40 or above 140 bpm.
• Unreadable. 'Unreadable' implies that there was too much interference during the recording. This could be electrical or sound interference.

The free Kardia Basic App permits local storage of ECGs in the Kardia App. A user can view a complete history of the ECG's they have recorded on their device. Any stored ECG can also be printed or e-mailed as a PDF directly from the mobile device. ECG storage can be turned off within the App.

The App is available in the Apple App Store or via Google Play in the UK and Ireland. In a recent medtech innovation briefing (MIB) published by the National Institute for Health and Care Excellence (NICE) the KardiaMobile by AliveCor was positively reviewed and recognised.

Features include

• Record a medical grade 6 lead or 1 lead ECG
• Records Lead I, II, III, aVR, aVL and aVFL ECG in realtime
• Connects using Bluetooth Low Energy Technology
• 1 metre wireless range
• Uses 3 stainless steel electrodes
• No messy gels or wires
• Dimensions - 9.0 cm x 3.0 cm x 0.72 cm
• Weight - 24 grams
• Approximately 12 months (200 hours) operating time on one CR2016 battery
• App features automatic AF, normal ECG, Bradycardia, Tachycardia and interference detectors and voice recording
• Save and email a PDF or print an ECG from your device
• Professional, CE and FDA approved clinically validated medical device

Supplied with

• One 3 volt CR2016 coin cell battery
• Getting started guide
• Two year warranty
• UK based after sales support
• Manufacturers part number AC-019-NUA-A

Compatible devices (Updated as of 6/4/19)>

iPhone

XR/XS/XS Max/X/8/8 Plus/7/7 Plus/6/6s/6s Plus/SE/5s (iOS 12.3), 5/5c (iOS 10.3.3)

iPad

Pro 12" (2nd Gen), Pro 10.5" (2nd Gen)/Pro 12", Pro 9"/9.7" (2017), Mini 4, 3, 2/Air 2/Air (iOS 12.3)

Google Pixel

3a/3a XL/3/3 XL/2/2 XL/Pixel/Pixel XL (Android 9.0.0)

Huawei

Mate 10 (Android 8.0.0)

LG

Nexus 5 (Android 6.0.1)

Motorola

Moto G Gen 2 (Android 6.0)

Samsung Galaxy

S10+/S10/S9+/S9 (Android 9.0.0), S9/S8+/S7 (Android 7.0.0), S8/S6 (Android 7.0.0), S5 (Android 6.0.1)

Samsung Note

Note 9 (Android 8.1.0), Note 8 (Android 8.0.0), Note 5 (Android 7.0.0)

Medisave supplies health professionals, business and home users.

• Credit card, PayPal and Amazon Payments accepted
• Free delivery over £25 ex VAT
• NHS, school or company purchase order - email accounts@medisave.co.uk
• Laser engraving
• Delivery to private or commercial addresses
• Google Certified Shop
• Registered with the Medicines and Healthcare products Regulatory Agency (MHRA)
• ISO9001 quality management system + ISO 140001 environmental
• Established 1999

Need some advice? Speak to our friendly team on 0800 804 6447

Ultra-portable, easy to handle and fast – the seca CardioPad-2

This new 12 lead ECG with touch screen from SECA is compatible with all leading EMR systems - emis, SystmOne, Vision and others with Wi-Fi connectivity and seca link software included as standard.

Time to increase your mobility for ECG recordings with the ultra-portable seca Cardiopad-2. As the the next generation of our innovative and trendsetting seca CardioPad it has become even lighter. Although it’s extremely compact, it features an in-built printer, renders 12 ECG traces simultaneously and is capable to process data to your the EMR system. It is fully equipped and has all functions aboard to support fast, precise and comfortable cardiac diagnostics.

Features:

• PDF ECGs automatically download to your pc following acquisition via Wi-Fi or LAN
• Ultra-lightweight easy to use device, weighing only 1.1kg
• 8" colour high-resolution multi-touch screen with anatomical electrode placement adviser - helps to correctly place the electrodes with zoom-in and rotate functions for optimal view
• Lead reversal, warnings and misplaced electrodes are immediately displayed before ECG acquisition
• On-screen preview of ECG - review recorded ECG prior to printing saving paper
• Flat device design enables easy cleaning, supporting infection control policies
• Advanced algorithms are implemented into seca CardioPad-2; with very high sampling frequency and a large frequency band, the seca CardioPad-2 delivers optimal signal quality making it the ideal tool for peadiatric ECGs
• ETM with ETM Sport Interpretation: one of the industries leading most renowned 12-lead ECG interpretation programs for adults and children
• ETM Sport: first automated ECG interpretation designed for athletes, based on the Seattle Criteria
• QTc interval - ideal for Mental Health
• QTc formulas: Bazett, Fredericia, Fremingham or Hodges
• Resting ECG Rhythm Strip: all 12 leads recorded for up to 4 minutes
• High volume internal memory: storage of up to 350 ECGs
• Dimensions: 230 x 160 x 30 mm (L x W x H)
• Weight: 1.1kg (including paper in the device)
• 3 year warranty as standard

Technical Data

• Power Supply- Rechargeable Batteries or Mains Adapter
• Net weight- 0.2 sts / 1.1kg
• Product width- 230 mm
• Product height- 160 mm
• Product depth- 30 mm
• Display- 8" colour high-resolution multi-touch screen with anatomical electrode placement
• ECG Channels- 12

Compatible with Emis

SystmOne Integration

Wireless Connectivity

Vision Compatibility
