Fryka cooling baths and cooling thermostats are compact, self-contained systems for cooling and temperature control of liquids in science and industry. Using natural refrigerants and high-quality stainless steel construction, they provide reliable operation over a working range from -40 °C to +20 °C with low maintenance requirements.
KT series cooling thermostats are equipped with an internal circulation pump and can be used for direct cooling in the bath tank or for external applications. KB series cooling baths are designed for direct cooling and tempering of liquids in the bath and can also be used with immersion circulators.
- Working temperature range: -40 °C to +20 °C (all models)
- Bath volumes of 8 L or 18 L depending on model
- Electronic temperature control with easy-to-read LED display
- Stainless steel bath tank and housing with integrated drain valve
- Low-noise, hermetically sealed refrigeration unit using natural refrigerant
- Optional circulation pump on KT models for external cooling tasks
Typical applications include cooling and thermostating of samples, reactors, measuring cells and general laboratory or pilot-scale processes requiring reliable low-temperature baths.
With a capacity of up to 18 litres and a working range of -40°C to +20°C: Designed for cooling and temperature controls of liquids, FRYKA cooling baths and cooling thermostats will convince you in a variety of applications for science and industry.
| KT Series - Cooling Thermostats |
KB Series - Cooling Baths |
| Fryka cooling thermostats are not only suitable for cooling tasks directly in the bath tank with internal circulation, but also for cooling externally connected applications. The cooling thermostats can be regulated via the easy-to-use control and an internally installed temperature sensor. If necessary, the control can be switched to an external sensor that records the temperature in the bath tank and thus enables direct control according to the relevant temperature. |
FRYKA Cooling baths are suitable for cooling and tempering liquids in the bath tank. The unit works with natural refrigerant and is very low-maintenance. The bath tank is also suitable for existing immersion circulators. |
|
Characteristics
- Environmentally friendly and energy-saving thanks to natural refrigerants
- Refrigeration unit: low noise, hermetically sealed, air-cooled, low maintenance
- Electronic temperature control with easy-to-read LED display
- No electronic control over the bath which is exposed to the vapours
- Casing parts and bath tank made of high quality stainless steel
- Drain valve allows liquid to be easily drained from the bath
- Housing protection rings at the top and bottom of the device
- Four mounting bolts (internal thread M8) on the corners of the bath for attaching support rods
- Including an external temperature sensor for measuring the temperature in the bath tank
- Removable bath cover and circulation pump
- Easy to clean: Interior free of fixtures, rounded corners
- Frame heating prevents condensation in the edge area
|
Characteristics
- Environmentally friendly and energy-saving thanks to natural refrigerants
- Refrigeration unit: low-noise, hermetically sealed, air-cooled, low-maintenance
- Electronic temperature control with easy-to-read LED display
- No electronic control over the bath which is exposed to the vapours
- Casing parts and bath tank made of high quality stainless steel
- Drain valve allows liquid to be easily drained from the bath
- Housing protection rings at the top and bottom of the device
- Four mounting bolts (internal thread M8) on the corners of the bath for attaching support rods
- Removable bath cover
- Easy to clean: Interior free of fixtures, rounded corners
- Frame heating prevents condensation in the edge area
|
Technical Data
| Model |
KT 08-42 |
KT 18-42 |
KB 08-41 |
KB 18-41 |
| Temperature Range |
-40°C to +20°C |
-40°C to +20°C |
-40°C to +20°C |
-40°C to +20°C |
| Bath Volume Capacity (L) |
8 |
18 |
8 |
18 |
|
Bath dimensions [WxDxH] cm
|
15 x 30 x 20 |
30 x 33 x 20 |
15 x 30 x 20 |
30 x 33 x 20 |
| External dimensions [WxDxH] cm |
34.5 x 45.5 x 66.5 |
49 x 52 x 66.5 |
34.5 x 45.5 x 52 |
49 x 52 x 52 |
| Electrical connection |
230 V / 50 Hz |
230 V / 50 Hz |
230 V / 50 Hz |
230 V / 50 Hz |
| Max. current |
2,5 A |
2,5 A |
2,5 A |
2,5 A |
| Weight |
35 kg |
40 kg |
30 kg |
40 kg |
| Circulation |
Pump |
Pump |
Not applicable |
Not applicable |
| Flow rate |
5 l/min |
5 l/min |
Not applicable |
Not applicable |
| Flow pressure |
0,15 bar |
0,15 bar |
Not applicable |
Not applicable |
| Hose connections |
12 mm |
12 mm |
Not applicable |
Not applicable |
