Vimex Full HD Endoscopy Camera
Vimex Full HD endoscopy camera with a 1/3-inch CMOS sensor, 1920 × 1080 imaging, USB image capture and three available camera-head configurations.
The Vimex Full HD camera is offered for arthroscopy, gynaecology, laparoscopy and urology. Its imaging controls, ergonomic head options and lockable endoscope coupling support configuration for compatible surgical optics.
Key features
Full HD CMOS imaging
A 1/3-inch CMOS sensor provides 1920 × 1080 imaging, with edge enhancement and automatic gain control.
Image-processing algorithms
Selective colour enhancement, smoke reduction and grid removal are available imaging functions.
Head controls and zoom
Illuminated function keys provide head-mounted controls. Digital zoom is 3×; optical zoom of 2× is listed for zoom-equipped configuration.
Lockable coupling
A sliding-ring locking mechanism supports attachment to compatible optics. Head options include zoom, fixed focal length and a 90° angled design.
Technical specifications
| Resolution | Full HD, 1920 × 1080 |
|---|---|
| Image sensor | 1/3-inch CMOS |
| Applications | Arthroscopy, gynaecology, laparoscopy, urology |
| Digital zoom | 3× |
| Optical zoom | 2×; confirm applicability to selected zoom head |
| Capture | USB image capture; built-in recording function |
| Image controls | Edge enhancement, automatic gain control, operating-mode settings |
| Video algorithms | Selective colour enhancement, smoke reduction, grid removal |
| Camera-head controls | Illuminated function keys |
| Endoscope connection | Sliding-ring lockable coupling |
| Head options | Full HD with zoom; Full HD fixed focal length; Full HD 90° angled |
Available camera-head configurations
| Full HD with zoom | Zoom-head option |
|---|---|
| Full HD fixed focal length | Fixed-focal-length head option |
| Full HD 90° angled | Angled head option |
Compatibility and configuration
Select the required camera-head option and confirm coupling compatibility with your endoscope. The listed optical zoom must be checked for the chosen head. Video-recording specification, outputs, storage format and the final accessory list should be confirmed in the quotation.
Supply and accessories
Confirm the camera control unit, selected head, coupling and any recording accessories in the supply configuration. Light sources, monitors and endoscopes are separate products unless expressly included.
Ordering information
For a quotation, provide the Full HD Endoscopy Camera model or required configuration, quantity, delivery location and intended use. Include your existing equipment, required accessories and consumables, and any installation, training or maintenance requirements.
Delivery, spares and service
Contact Nass Ventures to confirm availability, delivery arrangements, compatible spare parts and service requirements. The quotation will define the final configuration and supplied components.
Shipment
Benefit from reliable delivery options
Every day, we ship our laboratory equipment throughout Nigeria and internationally. We work with trusted and experienced logistics and courier partners to ensure safe and timely delivery. Shipping costs and delivery times depend on the items ordered and the recipient’s location. Alternatively, you may arrange to collect your order in person by appointment. Below is an overview of our shipping options and policies.
Shipping within Nigeria
All goods are insured as standard up to a value of ₦ equivalent of €25,000. Shipping costs are calculated based on the weight, dimensions, value of the shipment, and delivery destination within Nigeria. For detailed shipping information, please contact us directly—we will be happy to assist.
International shipping
For accurate international shipping costs, we require details of the specific product(s) you wish to order.
Please contact us by telephone or email for a tailored quotation.
Freight forwarding, sea or air freight
For large, heavy, or specialized equipment, we provide personalised quotations for road freight, sea freight, or air freight. Taking current logistics conditions into account, we aim to offer the best possible price-to-performance ratio.
Incoterms 2020
All shipments are handled in accordance with Incoterms® 2020 (ICC). Please contact us to confirm and agree on your preferred delivery terms.
Self-collection
If required, you may collect your goods in person by prior appointment. Please note that pricing and availability may vary between Nigeria and other countries.
Standard deliveries
Standard shipments within Nigeria are handled by reputable courier and logistics providers. Upon request, we can also arrange alternative carriers to meet specific delivery requirements.
Insurance
All deliveries are insured up to a maximum value of ₦ equivalent of €25,000. If the value of your goods exceeds this amount, we will contact you to arrange additional insurance coverage.
Delivery time
Delivery times depend on product availability and order volume. High-demand items may be subject to delays beyond our control. If you require urgent delivery, please inform us in advance, and we will do our best to accommodate your request.
