Miele laboratory washer PLW 8683 Safety DS10 MON
This washer-disinfector has been specially developed to reprocess respiratory protection equipment such as masks and regulators efficiently and safely. With its sophisticated technology and well thought-out operating concept, it sets standards in the industry and offers a particularly user-friendly solution compared to similar devices on the market. Fire and rescue services in particular benefit from the individually programmable flushing sequences, precise pressure adjustment and impressive cleaning performance.
Efficient and safe reprocessing solution
The focus is on a variable-speed heating pump that adjusts the rinsing pressure during different programme sections. This means that high pressure is used for stubborn soiling, while sensitive areas are rinsed gently. This leads to optimum results without using water or energy unnecessarily.
An integrated monitoring system continuously protects the rinsing process: rinsing pressure and spray arm controls immediately recognise if the load is blocked or the water pressure does not meet the specifications. The performance level of up to 500 litres per minute of the circulation pump also ensures consistently high quality.
As breathing masks, regulators and SCBAs are critical safety equipment, the reliability of the entire system is particularly important. This device is therefore equipped with special programmes that are precisely tailored to the disinfection and cleaning of sensitive components. In addition to the actual cleaning, efficient disinfection takes place at temperatures of up to 93 °C.
Thanks to the option of installing the appliance underneath and networking it via Wi-Fi, it can be integrated into almost any existing infrastructure. With its stainless steel panelling, sophisticated load carrier direct coupling and additional options such as integrable dosing pumps, it also covers very demanding application scenarios.
The operating software (M Touch Flex) is intuitive and allows flexible programming. A total of up to eight programmes and five free programme slots are available. This allows the user to customise the key parameters, such as dosing, rinse temperature or soaking time, to suit individual requirements. A display provides information on the remaining time and the current programme status for convenient process control.
Key technical data
- Floor-standing appliance with 2 washing levels and a usable wash cabinet volume of 145 litres
- Circulation pump with up to 500 l/min. and a shortest programme runtime of 28 minutes
- Variable-speed heating pump for optimum rinsing pressure and efficient use of resources
- Rinse temperatures of up to 93 °C for intensive disinfection
- Intelligent control (M Touch Flex) with 8 preconfigured programmes
- Water connections for cold, hot and demineralised water (1 connection each)
- Mains connection variants: 3N AC 400 V 50 Hz or AC 230 V 50 Hz
Other performance features, such as the splash-proof heating elements outside the washing compartment, demonstrate the high quality standards. The appliance offers a solid and durable design, proven by a tested 15,000 operating hours and a maximum floor load of 1,220 N/m².
Certifications and standards
For maximum product safety, this disinfection and cleaning appliance fulfils relevant standards such as EN 61010-1 and EN 61010-2-040 as well as the RoHS Directive 2011/65/EU. It also has the VDE mark for electrical safety and an IP 21 protection rating. This makes it clear that the design fulfils all quality and reliability requirements, which are particularly important in professional applications.
Application examples
- Fire service: reprocessing of six respiratory masks and six regulators in one batch, plus cleaning programmes for compressed air breathing apparatus carriers
- Rescue services: Disinfection of various ventilators and accessories at a water temperature of up to 93 °C.
- Industrial companies: Cleaning contaminated protective equipment, e.g. after handling chemicals in laboratories or production areas.
- Research facilities: Rinsing and disinfecting special items such as sensitive measuring instruments and laboratory tools.
FAQs
How are disinfectants dispensed
?
The device is equipped with liquid dosing as standard. An integrated dosing pump for rinse aid, detergent and neutralising agent ensures precise and automated agent addition.
Can different programmes be adapted precisely to different levels of soiling?
Yes, thanks to the freely programmable slots, important parameters can be adapted to the required cleaning and disinfection levels, such as pressure, temperature and run times.
Which connections are required for smooth operation
The appliance has connections for cold, hot and demineralised water. Different electrical connection variants (3N AC 400 V 50 Hz or AC 230 V 50 Hz) are also possible.
Is it possible to log the flushing processes?
Yes, process documentation for quality and safety purposes can be integrated via an optional interface. The appliance is also WLAN-capable ex works.
Can the device be flush-mounted?
Yes, thanks to its design, the model can be easily integrated into existing kitchen and laboratory furniture. The stainless steel and black panelling is particularly robust and easy to clean.
Conclusion
This washer-disinfector from Miele combines high performance with user-friendly operation. In particular, the variable-speed heating pump, precise dosing pump systems and comprehensive safety monitoring ensure excellent reprocessing results. With freely programmable user stations and a certified quality standard, the appliance is predestined for fire and rescue services, industrial operations and research facilities that require reliable and document-safe cleaning.
|
Effective for:
|
respiratory protection masksanaesthesia instruments
|
|
Filter:
|
multi-component filter system
|
|
Power (cleaning equipment):
|
9,3 kW
|
|
Standards (cleaning equipment):
|
EN 60529: IP21EN 61010-1EN 61010-2-040RoHS Directive 2011/65/EUVDE mark (electrical safety)
|
|
Type Dust Extractors, Cleaning Devices:
|
Lab washercleaning and disinfecting machine
|
| Shipping weight: |
83,00 Kg |
| Product weight: |
74,00 Kg |
| Dimensions: |
× × cm |
