Cherry medicine refrigerator ESSENTIAL MED 125

GFL Upright Freezer 6485: GFL Chest and Upright Freezers are used successfully in more than 70 countries all over the world. Both product ranges are designed for ultra-low temperatures of ± 0 °C to -40 °C and -50 °C to -85 °C, for long-term storage and quality assurance of organic substances and other materials.

GFL Upright Freezers are produced with high-quality, thoroughly tested materials only. They have been proven in continuous operation, work trouble-free, extremely silent and are maintenance-free. All models are equipped with microprocessor technique as well as with an interface module for comfortable remote control, monitoring and registration of the temperature values via PC.

Only a safe temperature protection ensures trouble-free long-term storage of cell lines, human, animal and plant tissues, fractions of the blood, vaccines, or reference cultures of micro-organisms, such as bacteria, yeasts, viruses and fungi.

• User-friendly microprocessor technique.
• Comfortable control panel with digital display to enter and read out all security-relevant data.
• Adjustable alarm limits for over- and under-temperatures (1 - 20 K).
• Additional control and alarm options, individually settable for different user applications.
• Maintains all display and alarm functions for 60 hours in case of a power failure (accumulator time allowance).
• Electronic alarm device and potential-free contact for connection to an internal alarm system, or to the central I&C system.
• RS 232 serial interface for trouble-free data transfer.
• Inside cabinet made completely of stainless steel and ex-proof.
• The magnetic sealing system reliably prevents freezing of the door seals.
• Equipped with three inside compartments (high 353 mm), each provided with an insulating door to prevent any loos of cold air.
• Wide range of accessories. Custom-made solutions on request.
• Energy-saving, maintenance-free cooling unit. The refrigerant is non-flammable. The all-around special insulation is up to 150 mm thick. The heat emission is only approx. 400 W.

GFL Upright Freezer 6445: GFL Chest and Upright Freezers are used successfully in more than 70 countries all over the world. Both product ranges are designed for ultra-low temperatures of ± 0 °C to -40 °C and -50 °C to -85 °C, for long-term storage and quality assurance of organic substances and other materials.

GFL Upright Freezers are produced with high-quality, thoroughly tested materials only. They have been proven in continuous operation, work trouble-free, extremely silent and are maintenance-free. All models are equipped with microprocessor technique as well as with an interface module for comfortable remote control, monitoring and registration of the temperature values via PC.

Only a safe temperature protection ensures trouble-free long-term storage of cell lines, human, animal and plant tissues, fractions of the blood, vaccines, or reference cultures of micro-organisms, such as bacteria, yeasts, viruses and fungi.

• User-friendly microprocessor technique.
• Comfortable control panel with digital display to enter and read out all security-relevant data.
• Adjustable alarm limits for over- and under-temperatures (1 - 20 K).
• Additional control and alarm options, individually settable for different user applications.
• Maintains all display and alarm functions for 60 hours in case of a power failure (accumulator time allowance).
• Electronic alarm device and potential-free contact for connection to an internal alarm system, or to the central I&C system.
• RS 232 serial interface for trouble-free data transfer.
• Inside cabinet made completely of stainless steel and ex-proof.
• The magnetic sealing system reliably prevents freezing of the door seals.
• Equipped with three inside compartments (high 353 mm), each provided with an insulating door to prevent any loos of cold air.
• Wide range of accessories. Custom-made solutions on request.
• Energy-saving, maintenance-free cooling unit. The refrigerant is non-flammable. The all-around special insulation is up to 150 mm thick. The heat emission is only approx. 400 W.

GFL Freezer 6641 Freezer
, 0 °C to -40 °C capacity
96 l, natural refrigerant Freezer

6641, substructure-compatible, with natural refrigerants microprocessor-controlled, with variable alarm system and potential-free contact for connection to an in-house alarm system.
Multifunctional control panel: with easily understandable symbols.
Alarm limit values for over/under temperature as well as alarm suppression (up to max. 240 minutes) can be set individually.
Automatic alarm and error display.
Input/recall of all safety-relevant values: set and actual temperature, over- and undertemperature.
Safety: Maintenance of the display and alarm functions for 48 hours in case of power failure (battery buffering).
Electronic alarm system and potential-free contact for connection to an in-house alarm system or the central control system (CCS).
EX-protected usable space, free from ignition sources: according to BG-I 850-0 as of 02/2009, made of stainless steel.
Three drawers on roller bearings made of stainless steel, manufactured with front insulating plastic covers to prevent loss of cold (useful heights 155, 160 and 165 mm).
External cooling coils ensure direct cold transfer from all sides, high freezing speed in the entire useful space and even temperature distribution.
Useful space door: 2-fold sealed (including one magnetic seal) and insulated, reliably prevents the door seals from freezing. With lockable handle, door hinges on the right.
Outer housing: made of electrolytically galvanized sheet steel, powder-coated, largely resistant to caustic soda, acids and heat.
Four castors ensure easy transport of the freezer to various places of use.
Insulation: 120 mm thick, seamless and diffusion-tight polyurethane foam on all sides.
Refrigeration system: according to accident prevention regulations (UVV). Energy-saving, maintenance-free refrigeration system.
The fully hermetic high-performance compressor, the air-cooled condenser, the component-tested safety pressure switch (pressostat) and other switching elements are mounted in the engine room in an easily accessible location.
Refrigerants: natural refrigerants - hydrocarbons.

FRYKA Underbench freezers TUS //logg

TUS and TUS //logg underbench freezers
The TUS underbench freezer is a small appliance for cooling and freezing for use in all laboratories, research and industry. Particularly due to its compact, space-saving design with a low-noise cooling unit, the underbench freezer is suitable for use directly under or even on the desk at work.

• Colour touch screen controller with representation of the temperature profile and user friendly menu structure
• Integrated data logger readable over USB stick for temperature profile and alarm events
• Battery-supplied alarm more than at least 72h with indication of the max. temperature reached at the interior
• Ethernet interface, in case of an alarm E-Mail will be sent
• Automatic and detailed supervision function of the refrigerating machine with failure analysis
• Remote maintenance with a worldwide access over the Internet
• Detailed user administration to protect the adjusted alarm- and temperature set points
• Registered access control
• Vacuum insulation: large interior space with small external dimensions and low power consumption
• All stainless steel casing
• Refrigeration unit: low noise, fully hermetically sealed, air-cooled, low maintenance
• TUS 80-100: two-stage cascade refrigeration system
• Foamed door with double door seal
• Air vents at front and right, making it suitable for installation under tables
• Voltage-free alarm contact for connection to an external alarm system
• 100mV/K-output for a connection to a temperature recording system
• Lockable door
• With inlaid grilles and 4 shelf rails
• Stackable unit, max. 2 units
• Electric door lock with access control and password available
• WiFi-Bridge to integrate the freezer in your wireless network available

FRYKA Freezers TS

TS and TS //logg freezer

The 100 litre TS freezer is a classic stand-alone unit. Wether in laboratories or industry, due to the compact, space-saving design combined with a low noise cooling unit, the TS 100 can be directly used in the workplace.

• Colour touch screen controller with representation of the temperature profile and user friendly menu structure
• Integrated data logger readable over USB stick for temperature profile and alarm events
• Battery-supplied alarm more than at least 72h with indication of the max. temperature reached at the interior
• Ethernet interface, in case of an alarm E-Mail will be sent
• Automatic and detailed supervision function of the refrigerating machine with failure analysis
• Remote maintenance with a worldwide access over the Internet
• Detailed user administration to protect the adjusted alarm- and temperature set points
• Registered access control
• Vacuum insulation: large interior space with small external dimensions and low power consumption
• All stainless steel casing
• Refrigeration unit: low noise, fully hermetically sealed, air cooled, low maintenance
• TS 80-100: two-stage cascade refrigeration system
• Foamed door with double door seal
• Side air vent, so suitable for installation directly on walls
• Voltage-free alarm contact for connection to an external alarm system
• 100mV/K-output for connection to a temperature recording system
• Lockable door
• With inlaid grilles and 4 shelf rails
• Electric door lock with access control and password available
• WiFi-Bridge to integrate the freezer in your wireless network available

FRYKA CHEST FREEZER TT //logg

TT //LOGG CHEST FREEZER

The TT //logg chest freezer is equiped with a colour touchscreen controller. The real-time rendering of the temperature profile and the integrated data logger for temperature profile and alarm events readable over USB stick are some of various new options. The controller allows the automatic and detailed supervision of the refrigerating machine with failure analysis. Over the Ethernet interface you can integrate the chest freezer into your network and with an internet connection you have access to the freezer all over the world. To protect the adjusted alarm- and temperature set points you have an detailed user administration and a registered access controll with password.

The TT //logg is available in different configurations and with its low-noise cooling unit. The compact, space-saving design, means the freezer can be used directly in the laboratory work space.

• Colour touch screen controller with representation of the temperature profile and user friendly menu structure
  • Integrated data logger readable over USB stick for temperature profile and alarm events
  • Battery-supplied alarm more than at least 72h with indication of the max. temperature reached at the interior
  • Ethernet interface, in case of an alarm E-Mail will be sent
  • Automatic and detailed supervision function of the refrigerating machine with failure analysis
  • Remote maintenance with a worldwide access over the Internet
  • Detailed user administration to protect the adjusted alarm- and temperature set points
  • Registered access control
• Vacuum-Insulation: large interior space with small external dimensions and low power consumtion
• Refrigeration unit: low noise, fully hermetically sealed, air-cooled, low maintenance
• All stainless steel casing
• Interior free of fixtures: no ignition sources, makes cleaning easy
• Circulating air vent, so suitable for installation directly on walls
• Voltage-free alarm contact for connection to an external alarm system
• 100mV/K-output for connection to a temperature recording system
• Lockable lid
• TT 85-90: two-stage cascade refigeration system

FRYKA Freezer TS

TS and TS //logg freezer

The 100 litre TS freezer is a classic stand-alone unit. Wether in laboratories or industry, due to the compact, space-saving design combined with a low noise cooling unit, the TS 100 can be directly used in the workplace.

• Vacuum insulation: large interior space with small external dimensions and low power consumption
• All stainless steel casing
• Refrigeration unit: low noise, fully hermetically sealed, air cooled, low maintenance
• TS 80-100: two-stage cascade refrigeration system
• Foamed door with double door seal
• Side air vent, so suitable for installation directly on walls
• Control unit with keyboard and integrated, optically isolated, mains-independent alarm (visual and audible signal, showing the maximum temperature during the disturbance, battery lasting around 72 hours)
• Voltage-free alarm contact for connection to an external alarm system
• 100mV/K-output for connection to a temperature recording system
• RS485 interface
• Lockable door
• With inlaid grilles and 4 shelf rails
