STEMA Full HD Endoscopy Camera System
Full HD endoscopy camera system supplied through Vimex, with a 1/3 inch CMOS sensor, USB image capture, image-processing functions and compatible camera-head choices.
The STEMA-branded camera shown by Vimex supports Full HD endoscopic imaging and an ergonomic camera head with illuminated function keys. The supplier describes a lockable endoscope connection and compatibility with zoom, fixed-focal-length and 90° angled Full HD camera heads.
Key features
Full HD imaging
The uploaded page specifies 1920 × 1080 resolution and a 1/3 inch CMOS sensor.
Image processing
Edge enhancement, automatic gain control and application-oriented operating settings are listed.
Additional video algorithms
The supplier lists selective colour enhancement, smoke reduction and removal of image-bundle grid patterns.
Head controls and connection
Illuminated function keys and a sliding-ring endoscope lock support operation and attachment.
Zoom specifications
The supplier quotes 3× digital and 2× optical zoom. Confirm the optical zoom capability of the selected camera head.
USB image capture
USB still-image capture is stated on the uploaded page. Confirm any video-recording module and its supplied licence or hardware separately.
Connection, image processing and head choices
Manufacturer illustrations show the sliding-ring connector, an example image-processing comparison and camera-head styles. The comparison is illustrative. Camera heads are configuration selections, not proof that three heads are supplied.
Supplier-listed specifications
| Manufacturer branding shown | STEMA; supplied through Vimex |
|---|---|
| Resolution | Full HD, 1920 × 1080 |
| Sensor description on uploaded page | 1/3 inch CMOS |
| Digital zoom | 3×, supplier specification |
| Optical zoom | 2× quoted by supplier; confirm applicability to the chosen camera head |
| Camera-head controls | Illuminated function keys |
| Endoscope connection | Lockable connection with sliding ring |
| Core image functions | Edge enhancement and automatic gain control |
| Additional image functions | Selective colour enhancement; smoke reduction; grid removal for image-bundle endoscopes |
| Compatible head styles listed | Full HD zoom; Full HD fixed focal length; Full HD 90° angled |
| Capture | USB image capture; exact recording capabilities and included module to be confirmed |
| Applications | Arthroscopy, gynaecology, laparoscopy and urology |
| Orderable model and connectors | Confirm exact control-unit/head references, outputs, power supply and supplied cables |
Configuration and supplied components
One camera system in the control-unit and camera-head configuration expressly listed in the quotation. Confirm coupler, endoscope connection, cables, capture options and documentation. Additional heads, endoscope, light source, light-guide cable, monitor, recorder and cart are separate unless itemised.
Handling and compatibility
Confirm camera-head type, endoscope coupling and monitor or recorder signal compatibility before ordering. Request the current model-specific instructions for camera-head care, cleaning and reprocessing. A still-image capture statement does not establish an included video-recording function.
Ordering information
Provide the product reference or range, quantity, delivery location and intended use. Specify the required model, configuration, accessories and consumables, existing equipment to be integrated, and any installation, commissioning, training or maintenance requirements. For configurable ranges, confirm the exact manufacturer references before ordering.
Delivery, spares and service
Contact Nass Ventures for pricing, availability, delivery arrangements, compatible spares and consumables, installation and after-sales support. The quotation will confirm the final supplied configuration, documentation, warranty terms and service arrangements.
